Introducing dotnet-monitor, an experimental tool

dotnet-monitor is an experimental tool that makes it easier to get access to diagnostics information in a dotnet process.

When running a dotnet application differences in diverse local and production environments can make collecting diagnostics artifacts (e.g., logs, traces, process dumps) challenging. dotnet-monitor aims to simplify the process by exposing a consistent REST API regardless of where your application is run.

This blog post details how to get started with dotnet-monitor and covers the following:

  1. How to setup dotnet-monitor

  2. What diagnostics artifacts can be collected; and

  3. How to collect each of the artifacts

Tour of dotnet-monitor

Setup dotnet-monitor

dotnet-monitor will be made available via two different distribution mechanism:

  1. As a .NET Core global tool; and

  2. As a container image available via the Microsoft Container Registry (MCR)

The setup instructions for dotnet-monitor vary based on the target environment. The following section covers some common environments.

In the default configuration dotnet-monitor binds to two different groups of URLs. The URLs controlled via the --urls parameter (defaults to http://localhost:52323) expose all the collection endpoints. The URLs controlled via the --metricUrls parameter (defaults to http://localhost:52325) only expose the /metrics endpoint. Since diagnostics artifacts such as logs, dumps, and traces can leak sensitive information about the application, it is strongly recommended that you do not publicly expose these endpoints.

Local Machine

To get started with dotnet-monitor locally, you will need to have .NET Core installed on your machine. You can then installdotnet-monitor as a global tool using the following command:

dotnet tool install -g dotnet-monitor --add-source --version 5.0.0-preview*

Once installed you can run dotnet-monitor via the following command:

dotnet monitor collect

Running in Docker

When consuming dotnet-monitor as a container image, it can be pulled from MCR using the following command:

docker pull

Once you have the image pulled locally, you will need to share a volume mount between your application container and dotnet-monitor using the following commands:

docker volume create diagnosticserver
docker run -d --rm -p 8000:80 -v diagnosticsserver:/tmp
docker run -it --rm -p 52323:52323 -v diagnosticsserver:/tmp --urls http://*:52323

Running in a Kubernetes cluster

When running in a cluster, it is recommend to run the dotnet-monitor container as a sidecar alongside your application container in the same pod. The sample Kubernetes manifest below shows how to configure your deployment to include a sidecar container.

apiVersion: apps/v1
kind: Deployment
  name: dotnet-hello-world
  replicas: 1
      app: dotnet-hello-world
        app: dotnet-hello-world
      - name: diagnostics
        emptyDir: {}
      - name: server
        - containerPort: 80
          - mountPath: /tmp
            name: diagnostics
      - name: sidecar
        - containerPort: 52325
        # args: ["--urls", "http://*:52323", "--metricUrls", "http://*:52325"]
          - name: diagnostics
            mountPath: /tmp

Unlike other target environments, this configuration does not make the diagnostics endpoint available on your host network. You will need to port forward traffic from your host to your target cluster.

To do this, obtain the name of the pod you wish to forward traffic to using the kubectl command:

$ kubectl get pod -l app=dotnet-hello-world
NAME                                 READY   STATUS    RESTARTS   AGE
dotnet-hello-world-dc6f67566-t2dzd   2/2     Running   0          37m

Once you have your target pod name, forward traffic using the kubectl port-forward command:

In PowerShell,

PS> $job = Start-Job -ScriptBlock { kubectl port-forward pods/dotnet- hello-world-dc6f67566-t2dzd 52323:52323 }

In bash,

$ kubectl port-forward pods/dotnet- hello- world- dc6f67566- t2dzd 52323:52323 >/dev/null &

Once you have started forwarding traffic from your local network to the desired pod, you can make your desired API call. As an example, you can run the following command:

In PowerShell,

PS> Invoke-RestMethod http://localhost:52323/processes

In bash,

$ curl -s http://localhost:52323/processes | jq

Once you have completed collecting the desired diagnostics artifacts, you can stop forwarding traffic into the container using the following command:

In PowerShell,

PS> Stop-Job $job
PS> Remove-Job $job

In bash,

$ pkill kubectl


The REST API exposed by dotnet-monitor exposes the following endpoints:

  • /processes

  • /dump/{pid?}

  • /gcdump/{pid?}

  • /trace/{pid?}

  • /logs/{pid?}

  • /metrics

In the sections that follow, we’ll look at the functionality exposed by each of these endpoints and use these endpoints to collect diagnostics artifacts.


The /processes endpoint returns a list of target processes accessible to dotnet-monitor.

To get a list of available processes, run the following command:

In PowerShell,

PS> Invoke-RestMethod http://localhost:52323/processes


In bash,

$ curl -s http://localhost:52323/processes | jq
    "pid": 1

As a convenience, when there is only one accessible process, dotnet-monitor does not require you to specify a process id for the remaining diagnostic endpoints.

Known Issue: When running locally the dotnet-monitor tools lists itself as one of the target processes.


The /dump endpoint returns a process dump of the target process.

To collect a process dump, run the following command:

In PowerShell,

PS> Start-Process http://localhost:52323/dump

In bash,

$ wget --content-disposition http://localhost:52323/dump

A dump artifact cannot be analyzed on a machine of a different OS/Architecture than where it was captured. When collecting a dump from a Kubernetes cluster running Linux, the resulting core dump cannot be analyzed on a Windows or a macOS machine. You can however use the existing dotnet-dump tool to analyze the generated dump in a Docker container using the following commands:

docker run --rm -it -v C:/dumpFiles:/dumpFiles /bin/sh

# Now in the context of the docker container
dotnet tool install -g dotnet-dump
/root/.dotnet/tools/dotnet-dump analyze /dumpFiles/core_20200618_083349

GC Dump

The /gcdump endpoint returns a GC dump of the target process.

To collect a GC dump, run the following command:

In PowerShell,

PS> Start-Process http://localhost:52323/gcdump

In bash,

$ wget --content-disposition http://localhost:52323/gcdump

Unlike a process dump, a GC dump is a portable format which can be analyzed by Visual Studio and perfview regardless of the platform it was collected on. To learn more about when to collect GC dumps and how to analyze them, take a look at our earlier blog post.


The /trace endpoint returns a trace of the target process. The default trace profile includes sampled CPU stacks, HTTP request start/stop events, and metrics for a duration of 30 seconds.

The duration of collection can be customized via the durationSeconds querystring parameter. The diagnostic data present in the trace can be customized via the profile querystring parameter to include any combination of the preset profiles:

  • CPU (CPU profiler),

  • Http (Request start/stop events from ASP.NET Core),

  • Logs (Logging from the EventSourceLogger from Microsoft.Extensions.Logging library); and

  • Metrics(Runtime and ASP.NET Core EventCounters).

For example, a request to /trace?profile=cpu,logs will enable the collection of the CPU profiler and logs.

In addition to the GET endpoint, there is POST version of the endpoint which allows you to specify what EventSource providers to enable via the request body.

To collect a trace of the target process, run the following command:

In PowerShell,

PS> Start-Process http://localhost:52323/trace

In bash,

$ wget --content-disposition http://localhost:52323/trace

The resulting .nettrace file can be analyzed with both Visual Studio and PerfView.


The /logs endpoint will stream logs from the target process for a duration of 30 seconds.

The duration of collection can be customized via the durationSeconds querystring parameter. The logs endpoint is capable of returning either newline delimited JSON (application/x-ndjson) or the Event stream format (text/event-stream) based on the specified Accept header in the HTTP request.

To start streaming logs from the target process, run the following command:

In PowerShell,

PS> Start-Process http://localhost:52323/logs

In bash,

$ curl -H "Accept:application/x-ndjson" http://localhost:52323/logs --no-buffer

{"LogLevel":"Information","EventId":"1","Category":"Microsoft.AspNetCore.Hosting.Diagnostics","Message":"Request starting HTTP/1.1 GET http://localhost:7001/  ","Scopes":{"RequestId":"0HM0N9ARKHVJK:00000002","RequestPath":"/","SpanId":"|88c401de-4df03365b379aaa4.","TraceId":"88c401de-4df03365b379aaa4","ParentId":""},"Arguments":{"Protocol":"HTTP/1.1","Method":"GET","ContentType":null,"ContentLength":null,"Scheme":"http","Host":"localhost:7001","PathBase":"","Path":"/","QueryString":""}}
{"LogLevel":"Information","EventId":"ExecutingEndpoint","Category":"Microsoft.AspNetCore.Routing.EndpointMiddleware","Message":"Executing endpoint \u0027/Index\u0027","Scopes":{"RequestId":"0HM0N9ARKHVJK:00000002","RequestPath":"/","SpanId":"|88c401de-4df03365b379aaa4.","TraceId":"88c401de-4df03365b379aaa4","ParentId":""},"Arguments":{"EndpointName":"/Index","{OriginalFormat}":"Executing endpoint \u0027{EndpointName}\u0027"}}


The /metrics endpoint will return a snapshot of runtime and ASP.NET Core metrics in the prometheus exposition format. Unlike the other diagnostics endpoints, the metrics endpoint will not be available if dotnet-trace detects more than one target process. In addition to being accessible via the URLs configured via the --urls parameters, the metrics endpoint is also accessible from the URLs configured via the --metricUrls. When running in Kubernetes, it may be suitable to expose the metrics URL to other services in your cluster to allow them to scrape metrics.

When deploying in-cluster, a common pattern to collect metrics is to use Prometheus or another monitoring tool to scrape the metrics endpoint exposed by your application. As an example, when running in Azure Kubernetes Services (AKS), you can configure Azure Monitor to scrape prometheus metrics exposed by dotnet-monitor. By following the instructions in the linked document, you can enable Azure Monitor to enable monitoring pods that have been annotated.

Like in the case of the other diagnostics endpoints, it is also possible to view a snapshot of current metrics by running the following command:

In PowerShell,

PS> Invoke-RestMethod http://localhost:52323/metrics

In bash,

$ curl -S http://localhost:52323/metrics

# HELP systemruntime_alloc_rate_bytes Allocation Rate
# TYPE systemruntime_alloc_rate_bytes gauge
systemruntime_alloc_rate_bytes 96784 1592899673335
systemruntime_alloc_rate_bytes 96784 1592899683336
systemruntime_alloc_rate_bytes 96784 1592899693336
# HELP systemruntime_assembly_count Number of Assemblies Loaded
# TYPE systemruntime_assembly_count gauge
systemruntime_assembly_count 136 1592899673335
systemruntime_assembly_count 136 1592899683336
systemruntime_assembly_count 136 1592899693336
# HELP systemruntime_active_timer_count Number of Active Timers
# TYPE systemruntime_active_timer_count gauge
systemruntime_active_timer_count 1 1592899673335
systemruntime_active_timer_count 1 1592899683336
systemruntime_active_timer_count 1 1592899693336
# ...
# (Output truncated)

While metrics collection is enabled by default when dotnet-monitor detects exactly one target process, it can be configured to disable to collection of metrics entirely via the --metrics parameter. In the example below, metrics collection will not be enabled.

dotnet monitor collect --metrics false


While we are excited about the promise dotnet-monitor holds, it is an experimental project and not a committed product. During this experimental phase we expect to engage deeply with anyone trying out dotnet-monitor to hear feedback and suggestions.

dotnet-monitor is currently committed as an experiment until .NET 5 ships. At which point we will be evaluating what we have and all that we’ve learnt to decide what we should do in the future.


We are excited to introduce the first preview of dotnet-monitor and want your feedback. Let us know what we can do to make it easier to diagnose what’s wrong with your dotnet application. We’d love for you to try it out and let us know what you think.
